Description

• Cast aluminum alloy body with heat exchanger designed to isolate the driver heat from the high efficiency LED’s
• Robust design for harsh environments and extended service life
• Patented corrosive resistant electrostatic power coating to withstand all environments
• Compact design, promotes high lumen output with improved reliability
• IP67 rated for dust and wet locations
• Marine gray is standard color, other colors are optional
• Tempered glass diffuser is standard, while polycarbonate is optional
• Designed for high mechanical strength and long-range lighting
• Advanced optical system, polycarbonate lens provides superior uniformity and reduces glare
• Lumen package from 4,000 to 53,000 lumens, efficacy up to 153 lm/W
• Beam angles include 10°, 30°, 60°,90°, 120° and Asymmetric
• Standard CCT is 5000K, 3000K is optional
• Input power ranging from 30W to 400W
• Operating voltage is 100-277 VAC
• Power Factor >93% @ 277VAC, THD <15%
• Operating temperature is -40℃ to 55℃ (-40℉ to 131℉)
• Surface mount trunnion bracket is standard; cable tray and pipe hangers are optional
• UL Listed – 1598
• Canada: CSA C22.2, No. 250
• Standard 5-Year Limited Warranty
